MOTOR
Yamaha, PW-ST System, 250W, 70 Nm, 25 km/h

DISPLAY
Yamaha, Side Switch, 1.7″ LCD, 7 functions

BATERÍA
InTube, 630 Wh

FAMILIA DEL CUADRO
Haibike, AllMtn Yamaha i630, Aluminium

HORQUILLA
RockShox, 35 Silver, Air, Travel= 160 mm, Aluschaft 1 1/8 – 1 1/2″ tapered, 15 x 110mm thru-axle Boost

AMORTIGUADOR
SR Suntour, Edge LO-R8, Air, Trunnion Mount M8x25

BRAZO DE BIELA
Haibike Components, The Crank +, Aluminium

FRENO (DELANTERO)
Tektro, Orion M745 , 203 mm, 4-piston disc brake

FRENO (TRASERO)
Tektro, Orion M745 , 180 mm, 4-piston disc brake

CÁMARA
Presta valve

LLANTAS
Rodi, Tryp 30, with eyelets, hollow rim, Aluminium

ABRAZADERA
Internal hexagon, 34.9 mm

CAMBIO
Shimano, Deore M5100

MANETA DE CAMBIO
Shimano, Deore M5100, Trigger switch, 11 Speed

EJE DE PEDALIER
Integrated in the motor

SPROCKET
Shimano, M5100, 11 – 51 teeth

CADENA
KMC, X11e

PLATO (DELANTERO)
Steel, 38 teeth

MANETA DE FRENO
Tektro, Orion M745, Aluminium

DISCO DE FRENO (DELANTERO)
Tektro, TR203

DISCO DE FRENO (TRASERO)
Tektro, TR180

MODELO
Continental, Trail King, 60-622, 29″ x 2.4″

BUJE RUEDA DELANTERA
Haibike Components, TheHub ++, 6-bolt standard

BUJE RUEDA TRASERA
Haibike Components, TheHub ++ Steckachse 12×148, 6-bolt standard

RADIOS
Sapim, Leader, Black

MANILLAR
Haibike Components, TheBar +++ Gravity , 780 mm

PUÑOS
Haibike, MTB grips

POTENCIA
Haibike Components, TheStem ++, A-head, Bar bore: 31.8 mm, 7.0 °

DIRECCIÓN
Feimin, A-Head Tapered, Ball bearing

SILLÍN
Selle Royal Vivo 1216HRN

SEAT POST
Haibike Components, TheSeatpost ++, Aluminium, 31.6 mm

PEDALES
Freeridepedal , Aluminium, with Reflector,

PESO MÁXIMO (KG)
120.0 kg

MODELO (TRASERO)
Continental, Trail King, 65-584, 27.5″ x 2.6″

LLANTA (TRASERO)
Rodi, Tryp 35, Aluminium, with eyelets, hollow rim
